To record in parking mode while the engine is off please connect the Hardwiring Power Cable (included in the box) or install a Power Magic Battery Pack (sold separately). The dash cam will automatically stop recording and power down. Video files are stored on the microSD card.ġ1. The BlackVue dashcam will power up and start recording. Use the pry tool to lift the edges of the windshield trim/molding and tuck in the power cord.ġ0. Skip to 12 for Hardwiring Power Cable setup.ĩ. Plug the cigarette lighter power cable into the cigarette lighter socket and the front camera.
Use the pry tool to tuck in the cable.įor 3CH: I f you want to use the interior camera and the connectivity module at the same time, use the USB hub (included in the package). Use the pry tool to lift the edges of the rubber window sealing and molding and tuck in the rear camera connection cable.įor 2CH: Connect the connectivity module to the front camera and attach it to the edge of the window. Connect the front camera (‘Rear’ port) and the rear camera (‘V out’) using the rear camera connection cable.Ħ. For 3CH (DMS Camera DMC100): Connect the front camera (USB port) and the infrared DMS camera (‘V out’) using the USB connection cable. Connect the front camera (‘Rear’ port) and the rear camera (‘V out’) using the rear camera connection cable.ĥ. For 3CH (IR Camera): Connect the front camera (USB port) and the infrared interior camera (‘V out’) using the infrared interior camera connection cable. Skip to procedure 12 for the hardwiring power cable setup.ĥ. Use the pry tool to lift the edges of the rubber window sealing and molding and tuck in the DMS camera connection cable.Ĭonnect the DMS camera (DC in) using the DMS camera hardwiring cable (2p) to a car fuse. Attach the DMS camera to the windshield or dashboard.Ĭonnect the front camera (‘Rear’ port) and the DMS camera (‘V out’) using the DMS camera connection cable. For 2CH (DMC200): Adjust the angle of the lens by rotating the body of the DMS camera and mounting bracket. For 2CH: Connect the front camera (‘Rear’ port) and the rear camera (‘V out’) using the rear camera connection cable.ĥ. Adjust the angle of the lens by rotating the body of the rear camera.ĥ. Peel off the protective film from the double-sided tape and attach the rear camera to the rear windshield. We recommend pointing the lens slightly downwards (≈10° below horizontal), so as to record video with a 6:4 road-to-background ratio.Ĥ. Adjust the angle of the lens by rotating the body of the front camera. Peel off the protective film from the double-sided tape and attach the front camera to the windshield behind the rear-view mirror.ģ.
Open the cover of the microSD card slot, gently push the card into the slot until it locks into place and close the cover.Ģ. Remove any foreign matter and clean and dry the windshield before installation.ĭo not install the product in a location where it can obstruct the driver’s field of vision.ġ. Install the rear camera at the top of the back windshield. Install the infrared interior camera at the top of the front windshield. Remove any foreign matter and clean and dry the windshield before installation.įor 3CH Camera Models: Install the front camera behind the rearview mirror. The latter part of this guide includes the installation of a parking mode add-on/accessory.įor 2CH Camera Models: Install the front camera behind the rearview mirror. Skip some parts if the camera model is one-channel. NOTE: This installation guide is for two-channel and three-channel cameras.
